US 6,499,200 B1 Slider for a slide fastener Koji Yamagishi,
Toyama-ken (Japan);
Hideyuki Matsushima,
Toyama-ken (Japan);
and Hisashi Yoneshima,
Toyama-ken (Japan) Assigned to YKK Corporation,
Tokyo (Japan) Filed on 26-Oct-2000, as Appl. No. YKK Corporation,
Tokyo (Japan) Int. Cl.7A44B 19/26
U.S. Cl. 24-429
16 Claims
US 6,499,200 B1
Slider for a slide fastener
Koji Yamagishi,
Toyama-ken (Japan);
Hideyuki Matsushima,
Toyama-ken (Japan);
and Hisashi Yoneshima,
Toyama-ken (Japan)
Assigned to YKK Corporation,
Tokyo (Japan)
Filed on Oct. 26, 2000, as Appl. No. 9/695,837.
Claims priority of application No. 11-308914 (JP), filed on Oct. 29, 1999.
Int. Cl.7A44B 19/26
U.S. Cl. 248212;429
16 Claims
1. A slider for a slide fastener comprising a zipper pull mounting portion provided on a top face of a slider body of the
slider; a connecting body disposed such that the connecting body traverses the top face of the slider body; at least one lateral
bar provided in a center portion of the connecting body; said lateral bar being mounted on the mounting portion such that
it is inserted therethrough; and a zipper pull formed of resilient body that is fixed to front and rear ends of the connecting
body so as to form a plurality of fixing portions; wherein said zipper pull is always urged to be fallen on a surface of the
slider body.
